Internal Keyway Tool

Internal Keyway Tool
Internal Keyway Tool
Product Code : Internal keyway tool
Product Description

Backed with the support of a highly proficient team, we are renowned as one of the topmost manufacturers and exporters of an extensive range of Internal Keyway Tool. We offer different sizes of tools for a wide range of keyway sizes. The offered Internal Keyway Tool can be easily used on a wide range of machines. Under the guidance of senior professionals, this tool is wisely manufactured using premium quality materials procured from reputed vendors of market. Prior to final dispatch in market, this tool is stringently tested on various standard quality parameters by experts.

Features:

  • Precise size and straightness of keyway produced
  • Wear resistant
  • Sturdy design

COMPARATIVE STUDY OF INTERNAL KEYWAY CUTTING ON DRILLING & BROACHING MACHINE

Sr. # K‐SLOT DRILLING BROACHING
1 Keyway can be accomplished In a subsequent operation after reaming. Keyway is accomplished after subsequent operation without boring or Reaming.
2 No separate setting required after reaming. Separate set‐up required.
3 Keyway accomplished with K slot. Keyway accomplished with broach.
4 Highest Geometrical accuracy Achieved with K slot tool Lowest Geometrical accuracy Achieved.
5 Highest positional accuracy. Low positional accuracy.
6 Accuracy dependent on fixture. Accuracy dependent on fixture.
7 Blind keyway possible. Blind keyway not possible.
8 Thru keyway possible. Thru keyway possible.
9 No additional manpower . Additional skilled manpower required.
10 No separate machine required. Separate machine required.
11 Negligible Space required to store the tool. Machine Occupies more floor space.
12 Low setting time on machine. High setting time on machine.
13 Low capital investment . High capital investment .
14 Suitable for batch production and mass production. Suitable for mass production.
15 Adaptable on any machine. Not adaptable on any machine.
16 Material handling time required. Material handling time required.
17 Low consumable cost of cutter. High consumable cost of broach.
18 Flexibility of increasing the operating range of keyway. No flexibility of increasing the operating range of keyway.
19 Lowest component rejection rate. Higher component rejection rate.
20 In house Tool Re sharpening Possible. In house Tool Re sharpening not possible.
21 Low maintenance cost. High maintenance cost.
22 Water soluble oil for coolant. Broaching oil for coolant.
